Compact shower sump system designed to meet the higher demands from today’s boating industry where more equipment is used; for example fresh water systems incorporating showers, dishwashing machines, galley sinks, etc.
Limited 3 Year Warranty Includes the Cartridge 1000 GPH bilge pump + Ultima Switch for automatic operation and a mesh filter for easy cleaning Multiple inlet ports for handling waste water from more than one tapping point Tight fitting lid to minimize splashing and odors Check valve on outlet stops water from flowing back into the tank. Intake hoses: 1 x 3/4″, 1 x 3/4″ or 1 x 1″, 1 x 1 1/8″ or 1 x 1 1/2″, Discharge hose: 3/4″
| Pump body: | Thermoplastic |
| Shaft seal: | Lip seal |
| Shaft: | Stainless steel (SS2343) |
| Part No. | Part No. USA | Description | Capacity 1.0 m head (13.6V/27.2V) | Capacity straight (13.6V/27.2V) | Voltage | Amperage | Fuse Size | Intake connection | Discharge connection |
| 32-57151-01 | 57151 | Shower Sump Multiports 1000 GPH 12V | 53 L/min – 844 GPH | 61 L/min – 972 GPH | 12 V | 3.4 A | 5 A | 1x ¾”, 1x¾” or 1×1″ | ¾” |
| 32-57151-02 | 57151-24 | Shower Sump Multiports 1000 GPH 24V | 53 L/min – 844 GPH | 61 L/min – 972 GPH | 24 V | 2 A | 3 A | 1×1⅛” or 1×1½” | ¾” |
| Length x Width | 280 x 210 mm – 11.42 x 8.26″ |
| Max height | 140 mm – 5.7″ |
| Weight | 0.9 kg – 2 lbs |
| Part No. | Part No. USA | Spare Parts Shower Sump |
| 32-54304 | 54304PK | Clear Sump Cover for Shower Sump |
| 34-28512 | 28512 | Cartridge Motor 1000 GPH 12V |
| 34-36303 | 36303 | Electronic Automatic Switch – Ultima Switch, 12/24V |
