Aqua Jet – WPS

Marine – Recreational / Water Pressure Systems

Quiet and pulsation-free even at low speeds, the new Aqua Jet Water Pressure Pump “WPS” series of five-chamber diaphragm pumps provides the perfect water pressure solution for both small and medium sized leisure and commercial boats. Efficient and compact, Aqua Jet pumps are particularly suitable where low amperage and sound levels in relation to water flow are placed at a premium – such as in shower and galley applications.

Categories: , ,
Johnson Pump
Features

Features

  • Available in capacities 2.4, 2.9, 3.5, 4.0 and 5.2 GPM – 12V and 24V
  • Whisper quiet operation; the Aqua Jet Five-chamber construction demonstrates dramatically lower noise and water pulsation characteristics, even at low speeds, compared to conventional three or four-chamber diaphragm pumps
  • Self-priming
  • Easy, low cost maintenance
  • Quick-connect hose or threaded connectors available
  • Integrated pressure switch turns pump on and off automatically when tap is opened and closed
  • Long service life
  • Operates in fresh or sea water
Aqua Jet WPS 2.4

Aqua Jet WPS 2.4

Technical data

Part No. Description Capacity Pressure Cut Off* Fuse Size Connection**
10-24604-03 Aqua Jet WPS 2.4 12V 9 l/min – 2.4 GPM 2.8 bar, 41 psi 10 A ⅜” BSP / hose ½”, ½” BSP / hose ¾”
10-24604-103 Aqua Jet WPS 2.4 12V 9 l/min – 2.4 GPM 2.8 bar, 41 psi 10 A ⅜” NPT / hose ½”; ½” NPT, ¾” hose
10-24604-04 Aqua Jet WPS 2.4 24V 9 l/min – 2.4 GPM 2.8 bar, 41 psi 5 A ⅜” BSP / hose ½”, ½” BSP / hose ¾”
10-24604-104 Aqua Jet WPS 2.4 24V 9 l/min – 2.4 GPM 2.8 bar, 41 psi 5 A ⅜” NPT / hose ½”; ½” NPT, ¾” hose
* Cut off pressure 2.1 bar/30 psi and 1.4 bar/20 psi available on request



Dimensions

Part No. Length Width Height Weight
10-24604-03 204 mm 197 mm 110 mm 1.6 kg
10-24604-103 8.02″ 7.76″ 4.33″ 3.5 lbs
10-24604-04 204 mm 197 mm 110 mm 1.6 kg
10-24604-104 8.02″ 7.76″ 4.33″ 3.5 lbs
Aqua Jet WPS 2.9

Aqua Jet WPS 2.9

Technical Data

Part No. Description Capacity Pressure Cut Off* Fuse Size Connection**
10-13405-03 Aqua Jet WPS 2.9 12V 11 l/min – 2.9 GPM 2.8 bar, 41 psi 10 A ⅜” BSP / hose ½”, ½” BSP / hose ¾”
10-13405-103 Aqua Jet WPS 2.9 12V 11 l/min – 2.9 GPM 2.8 bar, 41 psi 10 A ⅜” NPT / hose ½”; ½” NPT, ¾” hose
10-13405-04 Aqua Jet WPS 2.9 24V 11 l/min – 2.9 GPM 2.8 bar, 41 psi 5 A ⅜” BSP / hose ½”, ½” BSP / hose ¾”
10-13405-104 Aqua Jet WPS 2.9 24V 11 l/min – 2.9 GPM 2.8 bar, 41 psi 5 A ⅜” NPT / hose ½”; ½” NPT, ¾” hose
* Cut off pressure 2.1 bar/30 psi and 1.4 bar/20 psi available on request



Dimensions

Part No. Length Width Height Weight
10-13405-03 204 mm 197 mm 110 mm 1.6 kg
10-13405-103 8.02″ 7.76″ 4.33″ 3.5 lbs
10-13405-04 204 mm 197 mm 110 mm 1.6 kg
10-13405-104 8.02″ 7.76″ 4.33″ 3.5 lbs
Aqua Jet WPS 3.5

Aqua Jet WPS 3.5

Aqua Jet WPS 3.5 Technical Data

Part No. Description Capacity Pressure Cut Off* Fuse Size Connection**
10-13395-03 Aqua Jet WPS 3.5 12V 13 l/min – 3.5 GPM 2.8 bar, 41 psi 10 A ⅜” BSP / hose ½”, ½” BSP / hose ¾”
10-13395-103 Aqua Jet WPS 3.5 12V 13 l/min – 3.5 GPM 42.8 bar, 41 psi 10 A ⅜” NPT / hose ½”; ½” NPT; ¾” hose, ½” NPT, ¾” hose
10-13395-04 Aqua Jet WPS 3.5 24V 13 l/min – 3.5 GPM 2.8 bar, 41 psi 5 A ⅜” BSP / hose ½”, ½” BSP / hose ¾”
10-13395-104 Aqua Jet WPS 3.5 24V 13 l/min – 3.5 GPM 2.8 bar, 41 psi 5 A ⅜” NPT / hose ½”; ½” NPT; ¾” hose, ½” NPT, ¾” hose
* Cut off pressure 2.1 bar/30 psi and 1.4 bar/20 psi available on request



Dimensions

Part No. Length Width Height Weight
10-13395-03 236,5 mm 210 mm 116 mm 2 kg
10-13395-103 9.31″ 8,25″ 4.575″ 4.5 lbs
10-13395-04 236,5 mm 210 mm 116 mm 2 kg
10-13395-104 9.31″ 8,25″ 4.575″ 4.5 lbs
Aqua Jet WPS 4.0

Aqua Jet WPS 4.0

Aqua Jet WPS 4.0 Technical Data

Part No. Description Capacity Pressure Cut Off* Fuse Size Connection**
10-13406-03 Aqua Jet WPS 4.0 12V 15 l/min – 4.0 GPM 2.8 bar, 41 psi 10 A ⅜” BSP / hose ½”, ½” BSP / hose ¾”
10-13406-103 Aqua Jet WPS 4.0 12V 15 l/min – 4.0 GPM 2.8 bar, 41 psi 10 A ⅜” NPT / hose ½”; ½” NPT, ¾” hose, ½” NPT, ¾” hose
10-13406-04 Aqua Jet WPS 4.0 24V 15 l/min – 4.0 GPM 2.8 bar, 41 psi 5 A ⅜” BSP / hose ½”, ½” BSP / hose ¾”
10-13406-104 Aqua Jet WPS 4.0 24V 15 l/min – 4.0 GPM 2.8 bar, 41 psi 5 A ⅜” NPT / hose ½”; ½” NPT, ¾” hose, ½” NPT, ¾” hose
* Cut off pressure 2.1 bar/30 psi and 1.4 bar/20 psi available on request



Dimensions

Part No. Length Width Height Weight
10-13406-03 240 mm 214 mm 110 mm 2 kg
10-13406-103 9.46″ 8,42″ 4.33″ 4.5 lb
10-13406-04 240 mm 214 mm 110 mm 2 kg
10-13406-104 9.46″ 8,42″ 4.33″ 4.5 lb
Aqua Jet WPS 5.2

Aqua Jet WPS 5.2

Aqua Jet WPS 5.2 Technical Data

Part No. Description Capacity Pressure Cut Off* Fuse Size Connection**
10-13406-07 Aqua Jet WPS 5.2 12V 20 l/min – 5.2 GPM 2.8 bar, 41 psi 15 A ⅜” BSP / hose ½”, ½” BSP / hose ¾”
10-13406-107 Aqua Jet WPS 5.2 12V 20 l/min – 5.2 GPM 2.8 bar, 41 psi 15 A ⅜” NPT / hose ½”; ½” NPT, ¾” hose, ½” NPT, ¾” hose
10-13406-08 Aqua Jet WPS 5.2 24V 20 l/min – 5.2 GPM 2.8 bar, 41 psi 8 A ⅜” BSP / hose ½”, ½” BSP / hose ¾”
10-13406-108 Aqua Jet WPS 5.2 24V 20 l/min – 5.2 GPM 2.8 bar, 41 psi 8 A ⅜” NPT / hose ½”; ½” NPT, ¾” hose, ½” NPT, ¾” hose
* Cut off pressure 2.1 bar/30 psi and 1.4 bar/20 psi available on request



Dimensions

Part No. Length Width Height Weight
10-13406-07 240 mm 214 mm 110 mm 2 kg
10-13406-107 9.46″ 8.42″ 4.33″ 4.5 lbs
10-13406-08 240 mm 214 mm 110 mm 2 kg
10-13406-108 9.46″ 8.42″ 4.33″ 4.5 lbs
