SERIES S – SYSTEM 20-50ft

Zipwake Series S, the world’s first inexpensive dynamic trim-control system, incorporates a state-of-the-art family of durable, fast-acting interceptors. The system is fully automatic. It significantly enhances the boat’s performance, fuel economy, comfort and safety when accelerating, turning or running in a seaway.

  •  Dynamically eliminates uncomfortable and dangerous boat pitch and roll.
  • Automatically minimizes wave resistance and saves fuel.
  • Built-in quality, simplicity and easy expansion, yet still affordable.
  • Supports system integration with external devices via NMEA 2000 NETWORK
MOTION CONTROL FEATURES

MOTION CONTROL FEATURES

MODE MOTION FEATURE DESCRIPTION STANDARD FUTURE
Automatic Roll Active roll control YES
Advanced turn recognition YES
Coordinated turns YES
Easy sensitivity control YES
Pitch Curve-based pitch control YES
Pitch-offset control with quick save YES
Easy manipulation of pitch control curve YES
Basic pitch control curve from boat dimensions YES
Yaw Auxilliary steering, controllable by other onboard system YES
Manual Roll List control YES
Speed-progressive control wheel YES
Pitch Trim control YES
Speed-progressive control wheel YES
Yaw Steering control (calm sea or emergency steering) YES
Speed-progressive control wheel YES
SPECIFICATIONS

SPECIFICATIONS

Model KB300-S KB450-S KB600-S KB750-S KB300-S CHINE KB450-S CHINE
Width mm (in) 680 (26.8) 680 (26.8) 980 (38.6) 980 (38.6) 680 (26.8) 680 (26.8)
Depth 156 (6.1) 156 (6.1) 156 (6.1) 156 (6.1) 156 (6.1) 156 (6.1)
Height 274 (10.8) 274 (10.8) 274 (10.8) 274 (10.8) 274 (10.8) 274 (10.8)
Weight kg (lbs) 7.0 (15.3) 8.5 (18.7) 10.6 (23.3) 11.7 (25.8) 7.2 (15.9) 8.7 (19.3)
ORDERING DATA

ORDERING DATA

Model KB300-S KB450-S KB600-S KB750-S KB300-S CHINE KB450-S CHINE
Part No. 2011145 2011146 2011147 2011148 2011732 2011733
