RA111 – VHF – 1DB – 140 MM (5”) – RUBBER – 18 M (59′) COAXIAL CABLE.
The REGATTA & EMERGENCY series antennas are characterized by compactness and functionality.
RA111 is a small VHF antenna (140mm/5”,) protected by a tapered synthetic rubber tube that can be installed, on the sailboats or motorboats. It is equipped with 18m (59′) of coaxial cable and with a PL259 male connector.
| FREQUENCY RANGE | 156/162 MHz |
| GAIN | 1dBi |
| NOMINAL IMPEDANCE | 50 ohms |
| POLARIZATION | Vertical |
| SWR | ≤ 1,3 at 156,8 MHz |
| MAX INPUT POWER | 50 W |
| DC GROUND | No |
| TERMINATION | SO239 for PL259 male connector |
| ANTENNA LENGHT | 140mm/5” |
| ANTENNA WEIGHT | 220g/7,76oz |
