Technical details
| Part n. | Product Name | Retail price (€ ea.) | Tensione (V) | Assorbimento (A) | Fusibile (A) | Adescamento (m) | Portata (l/min) | Pressione (bar) | Portata ø 6 (l/min) | Portata ø 8 (l/min) | Portata ø 13 (l/min) | Tenuta | O-Ring | Hz | Bocche (BSPP) | Tubo (mm) | Protezione IP | Potenza Motore (W) | Peso (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 16408012 | UP9/OIL | Login | 12 | 7 | 10 | 1,5 | 9 | 5 | 0,42 | 1,2 | 8 | FKM | NBR | DC | 3/8″ | 13 | 67 | 180 | 2,5 |
| 16408013 | UP9/OIL | Login | 24 | 4 | 7,5 | 1,5 | 9 | 5 | 0,42 | 1,2 | 8 | FKM | NBR | DC | 3/8″ | 13 | 67 | 180 | 2,5 |
