Technical details
| Part n. | Product Name | Retail price (€ ea.) | Tensione (V) | Assorbimento (A) | Fusibile (A) | Portata (l/min) | Adescamento (m) | Pressione (bar) | O-Ring | Tenuta | Hz | Bocche (BSPP) | Tubo (mm) | Protezione IP | Potenza Motore (W) | Peso (kg) | Cavi (mm²) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1F409412 | UP8-MS/XC | Login | 12 | 12 | 20 | 10 | 3 | 4 | FKM | FKM | DC | 3/8″ | 13 | 67 | 150 | 1,9 | Yes |
| 1F409413 | UP8-MS/XC | Login | 24 | 8 | 15 | 10 | 3 | 4 | FKM | FKM | DC | 3/8″ | 13 | 67 | 150 | 1,9 | Yes |
