Technical details
| Part n. | Product Name | Retail price (€ ea.) | Tensione (V) | Assorbimento (A) | Fusibile (A) | Adescamento (m) | Portata (l/min) | Pressione (bar) | Portata ø 6 (l/min) | Portata ø 8 (l/min) | Portata ø 13 (l/min) | Tenuta | O-Ring | Hz | Bocche (BSPP) | Tubo (mm) | Protezione IP | Potenza Motore (W) | Peso (kg) | Cavi (mm²) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 16402012 | UP3/OIL | Login | 12 | 5 | 7,5 | 1 | 5.5 | 2 | 0.3 | 1 | 5.5 | FKM | NBR | DC | 3/8″ | 13 | 67 | 90 | 1,4 | Yes |
| 16402013 | UP3/OIL | Login | 24 | 3 | 4 | 1 | 5.5 | 2 | 0.3 | 1 | 5.5 | FKM | NBR | DC | 3/8″ | 13 | 67 | 90 | 1,4 | Yes |
