Chains

Chains

This chain made of steel grade 40 exhibits higher tensile strength and it is hot dip galvanized for enhanced corrosion resistance. They are produced following the strictest procedures and comply with international standards and class societies and regulations. The chain has an authenticity check “LFR” engraved link located every 30 cm.

Steel Grade 40
Hot Dip Galvanized
Extended quality testing
Certificate of Analysis for every drum included
Lofrans’ Authenticity Check -“LFR”.

We can supply you with 3 different brands of chains:

Lofrans chain
Plastimo chain
Alex Marine Master Chain

Specifications

Code	A (mm)	B (mm)	C (mm)	D (mm)	E (mm)	Weight / m (kg)	Available Pack (m)	Type	Breaking Load (kg)
72312	6	8,5	20	8	30,5	0,8	Carton Drum / 120	ISO 4565 / DIN 766	2400
72313	8	24	27,5	11,5	40	1,42	Carton Drum / 120	ISO 4565 / DIN 766	4300
72314	10	28	34	14	48	2,2	Carton Drum / 120	DIN 766	6750
72315	10	30	34,5	14,5	50	2,14	Carton Drum / 120	ISO 4565	6750
72316	12	36	39,6	15,6	60	3,23	Pallet Box/ 300	ISO 4565	9700
72408	14	41,5	47,4	19,4	69,5	4,37	Carton Drum / 200	DIN 766	13230
72409	16	45	54,6	22,6	77	5,72	Carton Drum / 200	DIN 766	17280
72749	6	18,5	20	8	30,5	0,8	Bag / 30	ISO 4565 / DIN 766	2400
72750	6	8,5	20	8	30,5	0,8	Bag / 50	ISO 4565 / DIN 766	2400
72751	8	24	27,5	11,5	40	1,42	Bag / 30	ISO 4565 / DIN 766	4300
72752	8	24	27,5	11,5	40	1,42	Bag / 50	ISO 4565 / DIN 766	4300
72753	10	30	34,5	14,5	50	2,14	Bag / 30	ISO 4565	6750
72754	10	30	34,5	14,5	50	2,14	Bag / 50	ISO 4565	6750
72755	12	36	39,6	15,6	60	2,14	Bag / 50	ISO 4565	9700
723121	6	8,5	20	8	30,5	0,8	Pallet Box/ 400	ISO 4565 / DIN 766	2400
723131	8	24	27,5	11,5	40	1,42	Pallet Box/ 400	ISO 4565 / DIN 766	4300
723141	10	28	34	14	48	2,2	Pallet Box/ 300	DIN 766	6750
723151	10	30	34,5	14,5	50	2,14	Pallet Box/ 300	ISO 4565	6750
723161	12	36	39,6	15,6	60	3,23	Pallet Box/ 300	ISO 4565	9700

Specifications
