X2- Vertical Windlass Dark Version

Main Features

Standard Equipment:

Specifications

Code	Gipsy For Chain	Gipsy For Rope	Line Speed at W.L	Max Line Speed	Maximum Pull	Motor size	Power Supply	Type	Net Weight	Amps at Working Load (A)	Working load (kg)
636703	8 mm, ISO 4565/ DIN 766	14 mm, 3-strand	20 m/min	40 m/min	1000 kg	1000 W	12 V	Low Profile	19 kg	117	150 kg
636704	8 mm, ISO 4565/ DIN 766	14 mm, 3-strand	20 m/min	40 m/min	1000 kg	1000 W	12 V	With Drum	20 kg	117	150 kg
636705	10 mm, ISO 4565	–	20 m/min	40 m/min	1000 kg	1000 W	12 V	Low Profile	19 kg	117	150 kg
636706	10 mm, ISO 4565	–	20 m/min	40 m/min	1000 kg	1000 W	12 V	With Drum	20 kg	117	150 kg
636707	10 mm, DIN 766	–	20 m/min	40 m/min	1000 kg	1000 W	12 V	Low Profile	19 kg	117	150 kg
636708	10 mm, DIN 766	–	20 m/min	40 m/min	1000 kg	1000 W	12 V	With Drum	20 kg	117	150 kg
